Workpiece type |
Roll / Wheel |
Grinding roller |
Grinding plate |
|
Length of workpiece器跳 (mm) |
≤5000 (Can be customized) |
-- |
-- |
|
Weight of workpiece (T) |
≤15 (Can be customized) |
||
|
Dia. of workpiece (mm) |
100～1000 |
-- |
≤3500 |
|
Configurations |
Servo power head + 3D sl分店ide table |
Manipulatior + Positione書電r |
Manipulatior + Positioner |
|
Cladding mode |
FCW or SAW |
FCW |
FCW |
|
Principle axis rotating speed (r/min) |
0.01～1（Servo speed regulation） |
-- |
-- |
|
Rotating speed of po從農sitioner (r/min) |
-- |
0.01～0.2（frequency control） |
-- |
|
Table diameter (mm) |
-- |
2000～3000 |
-- |
|
Boom travelling speed (mm/min) |
-- |
0.1～1000（Servo speed regulation） |
-- |
|
Wire diameter (mm) |
Φ1.6～Φ4.0 (Flux wier), Φ4.0 (Solid wire) |
||
|
Rated cladding current (A) |
630, 1000, 1250 |
||
|
Duty cycle |
100% |
||
Note: The above parameters are for T去這IME standard product configurations, 音行and can be customized according 森兒to the customer’s requi草道rements.
